300mm Segmented Diamond Saw Blade (300x25.4x10mm) for Concrete, Stone & Tile Cutting
Laser Diamond Metal Saw Blade – High-Precision Cutting Tool for Angle Grinders & Chop Saws
Our laser-welded diamond metal saw blade delivers superior cutting precision, ideal for installation on angle grinders and chop saws. Built with a solid steel wheel body, it drastically reduces breakage risk—boosting workplace safety, increasing productivity, cutting downtime, and lowering cost per cut compared to thin bonded cutoff wheels.
Unlike traditional bonded abrasives, this blade maintains its original diameter throughout its lifespan: ensuring consistent control, extended reach, and precise cuts. It also minimizes dust generation, keeping your work station cleaner for a more efficient, comfortable operation.
Product Specifications
| Specification | 115mm Model | 350mm Model |
|---|---|---|
| Diameter | 115mm | 350mm |
| Arbor Hole | 25.4/22.23/20/16mm | 25.4mm |
| Segment Width | 2mm | 3.2mm |
| Segment Height | 8mm | 8mm |
| Segment Number | 9 | 23 |
Applications
This 300 mm segmented diamond saw blade is built for cutting concrete, stone and tile, making it a practical choice for construction, renovation and stonework jobs.
- Cutting cured concrete slabs, walkways, kerbs and floor sections
- Sawing natural stone such as granite, marble, sandstone and limestone
- Cutting ceramic and porcelain wall and floor tiles
- Trimming stone steps, sills, paving and countertop pieces
- Brick, block and general masonry work on site
- Creating openings, expansion joints and repair cuts in concrete and stone surfaces
FAQ
What materials is this blade designed for?
It is intended for concrete, stone and tile cutting. It is not designed for cutting iron, steel or other metal.
What do the numbers 300x25.4x10mm mean?
300 mm is the blade diameter, 25.4 mm is the bore (arbor) size, and 10 mm is the segment height of the diamond rim.
What is the difference between a segmented rim and a continuous rim?
A segmented rim has separate diamond segments with gaps between them, which suits the concrete, stone and tile cutting jobs this blade is made for. If your work calls for a different finish or cutting behaviour, choose the rim type that matches the material.
Will this blade fit my machine?
The blade has a 25.4 mm bore, so it fits machines with a matching arbor. Because it is a 300 mm blade, it must be used on a machine rated to accept a blade of this diameter. Check your machine's blade capacity and arbor size before fitting.
Can it be used on different materials with the same blade?
Yes, the blade can be used across concrete, stone and tile work. For best results, match your cutting technique and machine settings to the material being cut, and always follow the instructions supplied with your machine.
Low Breakage Risk
Solid steel wheel body reduces fracture, enhancing workplace safety.
Consistent Precision
Maintains original diameter for stable, accurate cuts throughout lifespan.
Low Dust Generation
Cleaner work environment, improved operation comfort and efficiency.
